How to complete NS0-509 NetApp Certified Implementation Engineer—SAN Specialist exam?

1.

You are asked to serve iSCSI LUNs in an existing SVM on your AFF A220 using ONTAP 9.5. You verified that the iSCSI license is configured on your cluster and that the iSCSI protocol is enabled.

Referring to the exhibit, what is needed to allow hosts to log into the iSCSI target?

2. You are testing iSCSI LUN failover across a 4-node FAS9000 fabric-attached MetroCluster onfiguration.

In this scenario, which front end configuration is required for non-disruptive host LUN failover between sites?

3. Referring to the exhibit,

which two pairs of ports are currently configurable as FC SAN LIFs? (Choose two.)

4. You have a 4-node cluster with an AFF A300 HA pair and a FAS8200 HA pair. You plan on using the default storage efficiency settings. With inline data compaction, you estimate that you can save 6% of storage space. AFF A300 volumes that use under 5000 IOPS are moved to a FAS8200 using the volume move command.

In this scenario, what happens to the data after the volume is moved? (Choose two.)

5.

You have a requirement to serve LUNs with under 200 microsecond latency using local server lass memory. You also are required to use a shared SAN.

Using MAX Data as shown in the exhibit, which two LUN access protocols are supported with this solution? (Choose two.)

6. A company has 20 ESX hosts. Ten of the hosts are connected using FC, and the rest are connected over iSCSI. The FC host HBA queue depth is set to 32, and the iSCSI LUN queue depth is set to 64. The FC hosts are now experiencing random connectivity issues.

In this scenario, what would be the reason for the disconnects?

7. You want to ensure maximum performance of iSCSI LUNs on an AFF A220.

In this scenario, which two actions will accomplish this task? (Choose two.)

8. You are provisioning storage to an ESX host that uses iSCSI.

According to NetApp best practice, which three actions accomplish this task? (Choose three.)

9.

A customer has an AFF A700 connected to a Cisco switch and has verified connectivity but cannot see any LUNs. The customer issued the run -node scaling-01 -command fcp topology show command to verify the connection.

Referring to the exhibit, what needs to be enabled on the Cisco switch?

10.

A customer is using both FC and NVMe in a cluster. The customer needs to do some work on AFF_1.

Referring to the exhibit, what will happen?

11.

You have an existing 2-node AFF A300 cluster with premium bundle licensing applied. You need to have consistently low front end latency, and have determined that NVMe satisfies this requirement. Referring to the exhibit, which two actions would accomplish this task? (Choose two.)

12. You have a thin-provisioned LUN that was created by using the lun create -vserver vs1 – path /vol/vol1/lun1 -size 500G -ostype windows 2008 -space-reserve disabled -space-allocation disabled command. You verify that your Windows 2016 host reports 200 GB free on lun1. However, lun1 shows 0 bytes free on the storage cluster.

What should you do to solve this problem?

13. Referring to the exhibit,

what happens when you change the type for port 1a from target to initiator?

14. Which two features does Assymmetric Namespase Access (ANA) support? (Choose two.)

15. A customer that is using an AFF A220 has a problem with a host for a new FC LUN. Other LUNs on the same SVM are working properly. This LUN is not visible on the host.

Which configuration does the customer need to verify in their solution?

16. A customer has an existing 8-node cluster that consists of six FAS2650 nodes and two FAS2554 nodes. The customer wants to expand the cluster by adding two AFF A220 nodes.

Which resource would be used to determine whether this configuration is supported?

17. You deployed a new SVM for FC access, and you used the vserver fcr, create -vserver svm1 – status-admin up command to enable FC service on the SVM. You then created the LIFs for the FC protocol. When you review the status of the LIFs, they show that the admin status is up, but the operational status is down. You have already verified that the ports are physically connected.

In this scenario, what is the next step to bring the LIFs up?

18.

A customer wants to add a 2-port, 32 Gb FC card to support NVMe in an AFF A700 2-node cluster. Currently, there are cards in slots 1, 2, 4, 6, 8, and 9.

Referring to the exhibit, what is the number of the slot that should be used?

19.

Referring to the exhibit, which two elements are required for NVMe host access with ONTAP 9.5 and using supported AFF nodes? (Choose two.)

20. A customer is required to encrypt iSCSI traffic across their public network.

In this scenario, which method will accomplish this task?

21. You use iSCSI to present a LUN to a newly installed Windows 2016 Server. You have created the volume and LUN on the NetApp cluster. When you perform a hardware rescan on the Windows host, you cannot see the newly presented storage.

What are three reasons for this problem? (Choose three.)

22. As a system administrator, you perform a routine check of available storage space on your FAS2750. You notice that the vol_1 volume is approaching 100% capacity. The volume is configured with the space guarantee set to volume and the LUN reservation is disabled. You want to free up space in the volume without increasing its size.

Which action would accomplish this task?

23. An administrator reviews the Upgrade Advisor before performing an upgrade of their ONTAP cluster.

What information is detailed in the report? (Choose two.)

24. You want to create an additional SVM from the System Manager GUI to serve data only using block-based protocols. You know the SVM name, the aggregate containing the root volume, and the required protocols.

What other information is required to successfully create this SVM?
