1. Which is a family of solutions for data center designs that span compute, storage, networking, and management, serving as a blueprint for a customer’s Software Defined Data Center (SDDC) implementations? (Choose the best answer.)

2. Which three IPv6 features are supported in an NSX-T Data Center design? (Choose three.)

3. An architect is helping an organization with the Physical Design of an NSX-T Data Center solution.

This information was gathered during a workshop:

- Some workloads should be moved to a Cloud Provider.

- Extend network’s VLAN or VNI across sites on the same broadcast domain.

- Enable VM mobility use cases such as migration and disaster recovery without IP address changes.

- Support 1500 byte MTU between sites.

Which selection should the architect include in their design? (Choose the best answer.)

4. An architect is helping an organization with the Physical Design of an NSX-T Data Center solution.

This information was gathered during a workshop:

- There are six hosts and hardware has already been purchased.

- Customer is planning a collapsed Management/Edge/Compute cluster.

- Each host has two 10Gb NICs connected to a pair of switches.

- There should be no single point of failure in any proposed design.

Which virtual switch design should the architect recommend to the organization? (Choose the best answer.)

5. What selection is the key design benefit provided by a dedicated Edge Cluster VM or Bare Metal? (Choose the best answer.)

6. An architect is helping an organization with the Logical Design of an NSX-T Data Center solution.

This information was gathered during the Assessment Phase:

- There is a performance based SLA for East C West traffic.

- The business critical applications require prioritization of their traffic.

- One of the services is a file share and has a high demand for bandwidth.

Which selection should the architect include in their design? (Choose the best answer.)

7. Which NSX-T feature is used to allocate the network bandwidth to business-critical applications and to resolve situations where several types of traffic compete for common resources? (Choose the best answer.)

8. An architect is helping an organization with the Logical Design of an NSX-T Data Center solution.

This information was gathered during the Assessment Phase:

- Customer currently has a single 10 host vSphere cluster.

- Customer wants to improve network security and automation.

- Current cluster utilization and business policies prevent changing the existing vSphere deployment.

- High-availability is important to the customer.

Which three selections should the architect include in their design? (Choose three.)

9. An architect is helping an organization with the Conceptual Design of an NSX-T Data Center solution.

This information was gathered by the architect during the Discover Task of the Enagagement Lifecycle:

- There are applications which use IPv6 addressing.

- Network administrators are not familiar with NSX-T Data Center solutions.

- Hosts can only be configured with two physical NICs.

- There is an existing management cluster to deploy the NSX-T components.

- Dynamic routing should be configured between the physical and virtual network.

- There is a storage array available to deploy NSX-T components.

Which constraint was documented by the architect? (Choose the best answer.)

10. Which two benefits can be achieved using in-band management of an NSX Bare Metal Edge Node? (Choose two.)

11. An architect is helping an organization with the Physical Design of an NSX-T Data Center solution.

This information was gathered during a workshop:

- Any proposed solution must provide low latency.

- Any proposed solution must provide high throughput.

- Customer is running stock trading applications.

Which two selections should the architect recommend to meet high-performance workload requirements? (Choose two.)

12. Which selection is associated with the Review Task of the Engagement Lifecycle? (Choose the best answer.)

13. An architect is helping an organization with the Logical Design of an NSX-T Data Center solution.

This information was gathered during the Assessment Phase:

- NSX-T will span across two sites for disaster recovery.

- Public Load Balancer VIP should be accessible from a secondary site.

- Distributed Firewall Policies should be available at a secondary site.

- Routing capabilities should be maintained after failure.

- NAT capabilities are required.

Which two selections should the architect include in their design? (Choose two.)

14. An architect is helping an organization with the Conceptual Design of an NSX-T Data Center solution.

Which risk is documented by an architect? (Choose the best answer.)

15. An architect is helping an organization with the Logical Design of an NSX-T Data Center solution.

This information was gathered during the Assessment Phase:

- Data between two networks connected over a public network needs to be encrypted.

- Certificate authentication is required.

- Dynamic route learning is preferred.

Which selection should the architect include in their design? (Choose the best answer.)
